Product Name：Class TD

Features：

1. Class TD circuit, 2 channel, 2U & 3U. Provide 1200w, 1800w, 2000w ,2400w, 3000w for choose.

2. Using class A magnetic core high voltage ring transformer, large volume capacitor，makes the output current more strong, output power more bigger.

3. Use original America ON transistor(MJL21193/94, MJL21195/96), assure low frequency strong, high frequency sweet & clear.

4. Perfect protection: Power-on buffer, overheating protection, short circuit protection, output DC protection and other functions.

5. Support 2ohm impedance，Sensitivity: 0.775V/1V/1.4V.

6. Applications: Large touring performance, Bar, Large stadium.
